Description
Grandstream GRP2601 P IP Phone Jeddah
The Grandstream GRP2601P IP Phone Jeddah is an essential 2-line model features a sleek design and a suite of next-generation features including 5-way voice conferencing to maximize productivity, integrated PoE (GRP2601P), EHS support for Plantronics, Jabra, and Sennheiser headsets and multi-language support. The GRP2601P Jeddah offers an easy-to-use and easy-to-deploy voice endpoint, built for the basic needs of on-site or remote desktop workers and designed for easy deployment by enterprises, service providers and other high-volume markets. For cloud provisioning and centralized management, the Grandstream GRP-2601P IP Phone Jeddah is supported by Grandstream’s Device Management System (GDMS), which provides a centralized interface to configure, provision, manage and monitor deployments of Grandstream endpoints. The GRP series includes carrier-grade security features to provide enterprise-level security, including secure boot, dual firmware images and encrypted data storage.
GRANDSTREAM GRP2601 P FEATURES
- 2 SIP account, 2 lines
- GDMS online device management and provisioning
- 5-way audio conferencing for easy conference calls
- Equipped with noise shield technology to minimize background noise
- Electronic Hook Switch (EHS) support for Plantronics, Jabra, and Sennheiser headsets
- The GRP2601P includes built-in PoE to power the device and give it a network connection
- Enterprise-level protection including secure boot, dual firmware images and encrypted data storage
GRANDSTREAM GRP2601 P SPECIFICATIONS
- Protocols/Standards :
- SIP RFC3261, TCP/IP/UDP, RTP/RTCP, RTCP-XR, HTTP/HTTPS, ARP, ICMP, DNS(A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP, LDAP, TR069, SNMP, 802.1x, TLS, SRTP, IPv6
- Network Interfaces :
- Dual switched auto-sensing 10/100 Mbps Ethernet ports, integrated PoE (GRP2601P only)
- Graphic Display :
- 132 x 48 (2.21’’) LCD display
- Feature Keys :
- 4 XML programmable context sensitive soft keys, 5 (navigation, menu) keys. 8 dedicated function keys for: MESSAGE(with LED indicator), TRANSFER,HEADSET, MUTE, SEND/REDIAL, SPEAKERPHONE, VOL+, VOL
- Voice Codecs and Capabilities :
- Support for G.729A/B, G.711µ/a-law, G.726, G.722(wide-band), G.723,iLBC, OPUS, in- band and out-of-band DTMF(in audio, RFC2833, SIP INFO), VAD, AEC, CNG, PLC, AGC
- Telephony Features :
- Hold, transfer, forward, 5-way conference, call park, call pickup, downloadable phonebook(XML, LDAP, up to 2000 items), call waiting, call log(up to 800 records), off-hook auto dial, auto answer, click-to-dial, flexible dial plan, hot-desking, personalized music ringtones and music on hold, server redundancy and fail-over
- Auxiliary Ports :
- RJ9 headset jack (allowing EHS with Plantronics & Jabra &Sennheiser headsets)
- Base Stand :
- Yes, 1 angle position available (45°), Wall Mountable (*wall mount sold separately)
- QoS :
- Layer 2 QoS (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS
- Security :
- User and administrator level passwords, MD5 and MD5-sess based authentication, 256-bit AES encrypted configuration file, SRTP, TLS, 802.1x media access control, secure boot
- Multi-language :
- English, Chinese, Korean, Japanese, German, Italian, French, Spanish, Portuguese, Russian, Croatian and more
- Upgrade/Provisioning :
- Firmware upgrade via FTP/TFTP / HTTP / HTTPS, mass provisioning using GDMS/TR069 or AES encrypted XML configuration file
- Power & Green Energy Efficiency :
- Universal Power Supply Input 100-240VAC 50-60Hz;
- Output +5VDC, 600mA;
- PoE: IEEE802.3af Class 1, 3.84W; IEEE802.3az (EEE) (GRP2601P Only)
- Temperature and Humidity :
- Operation: 0°C to 40°C Storage: -10°C to 60°C
- Humidity: 10% to 90% Non-condensing
- Physical Dimension:
- 208mm (L) x 180mm (W) x 63.4mm (H) (with handset)
- Unit weight:650g;
- Package weight:810g (860g for GRP2601)
